Universal 5 Volt Electric Gauge Meter Sender Oil

AUTO TUNING SUPPLY Universal 5 volt Electric Gauge Meter Sender Oil Fuel Pressure Sensor 100 psi

Item Condition - Brand New in original Packing



Product Description

BRAND NEW 100 PSI PRESSURE SENDER WITH CONNECTOR
  Features:

• 100% brand new with high quality metal case (not plastic)

• Works for oil,fuel,diesel,gas,water,air pressure.
• Can be used with oil, water, fuel, air, etc.
• Easy to install with included connector (wiring instructions below)


Specifications:100 psi

• Input 0-100 psi

• Output: 0.5V – 4.5V linear voltage output. 0 psi outputs 0.5V, 50 psi outputs 2.5V, 100 psi outputs 4.5V.
• Accuracy: within 2% of reading (full scale).
• Thread: 1/8”-27 NPT.
• Wiring connector: water sealed quick disconnect. Mating connector and wire harness (pigtail) is included.
• Wiring: Red for +5V. Black for ground. Green for signal output.
• Weight: 55 g
• Overload Capacity: 2-4 times;
• Working Temperature: -40—+120ºC;
• Compensation Temperature: -20—+80ºC;
• Protection Class: IP67;
• Pressure Medium: The gas and liquid which is compatible with 316L stainless steel;
• Load Resistance: ≤ (supply power-6.5V/0.02A)Ω;
• Long-term stability: Less than 0.1%FS/year;
• Temperature Effect on Zero: Typical:0.02%FS/ºC; Maximum:0.05%FS/ºC;
• Temperature Effect on Sensitivity: Typical:0.02%FS/ºC; Maximum:0.05%FS/ºC;
• Shock Resistance: 1000g;
• Anti-Shock: ≤+/-0.01%FS(X,Y,Z axes, 200Hz/g);
• Response Time: ≤1ms;
• Insulation Resistance: >100mΩ 500VDC;
• Explosion-proof Class: ExiaTTCT6;
• Electromagnetism Compatibility: EN50051-1.



Package Contents

PACKAGE INCLUDES 1 PRESSURE SENSOR WITH POPULATED WIRE CONNECTOR
